MS2003+

Velocity sensor

The MS2003+ velocity sensor is best suited for vibration monitoring according to DIN 4150. Its excellent dynamic and the broad frequency range fully cover the needs of the engineers in charge of structural dynamics.
The rugged construction of the MS2003+ is designed to withstand rough outdoor use. Each axis of the MS2003+ is calibrated individually. The sensor is delivered with a calibration certificate.

Main features

  • Velocity sensor with linearized frequency response and built-in amplification
  • Conforms to DIN 45669 class 1
  • Protection: IP 65
  • Measuring ranges: ±11.4 cm/s (f>9 Hz), down to 1.2 cm/s (f=1 Hz)
  • Frequency range : 1 – 350 Hz
  • Dynamic range: >130 dB
